DJI DOCK

For roads less Traveled

DJI Docks are rugged, reliable, and built to operate 24/7, day or night, rain or shine. Each DJI Dock houses a Matrice 30 where it can land, recharge, takes off, and execute missions programmed in DJI FlightHub 2.

We do in house software integration

Fill In the form to Contact Our Dev Team.

Enquire Now On the In house software solutions we offer

Unlock the full potential of DJI drones with our in-house software development services. Elevate your aerial missions with intuitive flight planning, autonomous navigation, data analytics, and custom integrations. Experience the future of drone technology with us today.

3 + 2 =

A Powerful Industrial solution

DJI Dock features:

Integrated and Easy to Deploy

 The DJI Dock is highly-integrated with hardware to improve functionality. This includes wide-angle security camera, integrated weather station, internal omni-directional antenna, RTK module, and edge computing expansion slot.

Rugged, Reliable, Waterproof Design

The DJI Dock is rated IP55 and the core internal components IP67, making it waterproof and dustproof even when open. The Dock interior is climate controlled for safe charging temperatures, even when the outside climate is -35°C to 50°C.

Emergency Power Supply

In case of a power outage, with up to 5 hours of battery life the Dock’s internal battery will take over to keep the dock operational and make sure the M30 lands safely from its mission.

Fast Charging, Fast Turnaround

Fast charge and take off thanks to TEC air conditioning that cools the drone batteries, enabling charging from 10-90% in just 25 minutes2.

Highly Customizable Design

Cloud API opens up Dock functionality to developers and system integrators, who can set up a custom, private server.

DJI Docks have edge computing expansion slots that enable pre-processing of media files, and more, to further improve operational efficiency.

DJI Dock Workflow

Automated Deployment

DJI Dock will automatically deploy a fully charged Matrice 30 to conduct your inspection mission.

Remote Data Capture

Automonmously & remotely capture inspection data and images of your target subject.

Real-time Data Sharing

Real-time data sharing through cloud-connected management software, allowing instant data transfer and reporting.

Return to Home and Recharge

Matrice 30 Drone will autonomously land back on its DJI Dock and begin recharging its batteries for the next mission.

Simple Setup

One DJI Dock weighs less than 105 kg and has a <1 square-meter footprint. Setup only requires ground fixation, access to power and internet, and quick configuration via the DJI RC Plus remote controller.

DJI DOCK SPECIFICATIONS

Specification

Value

Total Weight 90 kg
Dimensions

Cover Open (Weather Station excluded): 1,675 mm×895 mm×530 mm (L×W×H)

Cover Closed (Weather Station excluded): 805mm×895mm×840 mm (L×W×H)

Input Voltage 100-240 VAC, 47-63 Hz
Max Input Power 1,500 W
Operating Temperature -35 to 50° C (-31 to 122° F)
Ingress Protection Rating IP55
Number of Drones Accommodated 1
Max Allowable Landing Wind Speed 12 m/s
Max Operating Altitude 4,000 m
Max Operating Radius 7,000 m
Receiving Frequency of RTK Base Station Satellite

Simultaneously receive:

GPS: L1 C/A, L2, L5

BeiDou2: B1l, B2l, B3l

BeiDou3:B1l, B1C, B2a, B3l

GLONASS:L1, L2

Galileo: E1, E5A, E5B

Positioning Accuracy of RTK Base Station

Horizontal: 1 cm+1 ppm (RMS)

Vertical: 2 cm+1 ppm (RMS)

Charging Performance
Output Voltage 18 to 26.1 V
Charging Time

25 minutes

Note: This is if the ambient temperature is 25°C (77° F), and the aircraft is charged from 10% to 90%.

Video Transmission
Video Transmission System O3 Enterprise
Operating Frequency

2.4000-2.4835 GHz

5.725-5.850 GHz

Antennas 4 antennas, 2T4R
Transmitter Power (EIRP)

2.4 GHz: <33 dBm (FCC); <20 dBm (CE/SRRC/MIC)

5.8 GHz: <33 dBm (FCC); <14 dBm (CE); <23 dBm (SRRC)

Air Conditioning System
Operating Voltage 48 VDC
Air Conditioning Type TEC Air Conditioning
Backup Battery
Battery Capacity 12 Ah
Output Voltage 24 V
Battery Type Lead-acid Battery
Backup Battery Life > 5 hours
Network Access
Ethernet Access 10/100/1000Mbps Adaptive Ethernet port
Sensor
Wind Speed Sensor Supported
Rainfall Sensor Supported
Ambient Temperature Sensor Supported
Water Immersion Sensor Supported
In-cabin Temperature Sensor Supported
In-cabin Humidity Sensor Supported
Vibration Sensor Supported
Integrated Security Camera (On Cover)
Resolution 1920×1080
Field of View (FOV) 180°
Auxiliary Light Supported, Auxiliary White Light
Lightning Protection
AC Power Port 40 kA (8/20μs waveform), meets EN/IEC 61643-11 TYPE 2 protection level requirements
Ethernet Port 1.5 kA (8/20μs waveform), meets EN/IEC 61643-21 CATEGORY C protection level requirements
Supported Software
Applications DJI Pilot 2 (connects to DJI Dock via DJI RC Plus for configuration and commissioning)
Cloud Platform

DJI FlightHub 2

3rd Party Platforms through DJI Cloud API

Expansion Capability
Open Protocol DJI Cloud API
Edge Computing Internal power supply, data interface, and installation space

DJI Dock Applicable Industries

Power & Utility

Leverage remote monitoring to automate utility asset inspection and incident-based alerting.

Inspect critical infrastructure and identify anomalies in real-time to prevent outages and minimise asset downtime. Conduct frequent, repeatable and accurate data collection  and identify failing equipment and hot spots with thermal and zoom cameras.

Read More

Mining

Conduct assessments of confined spaces and areas that would otherwise be visually inaccessible or too hazardous for human intervention.

Evaluate the condition of mine shafts, sumps and boreholes; perform in-service remote inspection and avoid costly shutdowns; verify new pipeline construction prior to commissioning; and observe vehicle movements and stockpile measurements.

Read More

Construction

Construction / infrastructure

Monitor site productivity with persistent visual data streams and centralised digital data management.

Build up to date high-resolution maps and 3D models to obtain a better view of the site, share with stakeholders and collaborate with staff. This data can also be used to track vehicle movements and calculate earthworks and stockpile measurements to improve forecast planning and reduce unnecessary costs.

Read More

Oil & Gas

Minimise refinery downtime, reduce operation and maintenance costs, improve on-site safety and prevent serious failures.

Deploy autonomous drones on pre-scheduled missions to immediately detect leaks, faults, structural damage, environmental hazards, failures and other faults. This information enables maintenance teams to be more reactive and allows them to perform their daily tasks based on timely and accurate data.

Read More

Security / Surveillance

Conduct persistent surveillance along predefined routes or launch for on-demand monitoring.

Operating in a covert capacity, drones increase the surveillance overlap against CCTV infrastructure, reduce blindspots, offer a changeable and unique perspective and provide continuous target tracking.

Where static surveillance sensors can be identified through reconnaissance and invite malicious workarounds, drones benefit for being uniquely positioned.

Read More
